Juntai Tube Settler
TUBEdek sedimentation technology employs modular channels containing interlocking V-profile plastic elements. This design maximizes hydraulic efficiency within the lamellar clarification process, substantially boosting suspended solids removal. Consequently, it lowers both spatial requirements (footprint) and operational expenditures for potable and effluent treatment facilities.
Distinguished by exceptional adaptability, the system offers flexible implementation. Operators can customize the installation angle, profile length, and overall module dimensions to address precise project specifications.
Such tailored configurations optimize treatment outcomes and generate significant plant economies. Given its superior clarification performance and capacity to comply with strict regulatory requirements, TUBEdek is especially effective for installations experiencing elevated influent volumes and contaminant loading.
Our advantage
Enhanced separation process improves solids discharge
Mechanical strength simplifies installation and maintenance
Reduced tank footprint minimizes space and cost
High quality standards and materials enables long and reliable service life
| Juntai Lamella Plate Techinal Sheet | |||
| Product Pic |  |
||
| Model | JTLP 41.50 | Shape | Hexagonal - Chevron |
| Dimension | 1220 * 44 mm (±2 mm) The length can be customized |
Thickness | 1 mm (±0.1mm) |
| Color | White or Customized | Material | Strengthen the outdoors PVC+UV |
| Sedimentation Area /55° Slope | 13 m2/m3 | Hydraulic Radius | 17 mm |
| 4 Ft2/ft3 | |||
| Module Height(Vertical) | 500-2000 mm | Module Height(Standard) | 1000 mm |
| 20-79 inches | 40 inches | ||
| Application | Potable and process water | ·Surface water ·Groundwater ·Filter backwash water |
|
| Waste Water | ·Flocculated water ·Stormwater ·Humus tanks behind fixed-film processes |
||
| Continuous operation temperature | 55 ℃ | Max.operation temperature (short term) | 60 ℃ |
| 131 ℉ | 140 ℉ | ||
| Service Life | More than 20 years by strengthen outdoor PVC raw materials + anti-ultraviolet formula | ||
| Old tube settler | VS | Newest tube settler |
 |
|
 |
| ● Simple structure with Medium settlement efficiency ● Short settlement distance and small footprint. |
● Enhanced separation process improves solids discharge. ● Further Reduced Footprint saves space and cost. ● Large channel cross-section, High settlement efficiency, more resistant to anti clogging than honeycomb tube settlers |
|
| ● Installed with glue or welding,Replacement is relatively difficult. | ● Simplifies installation and maintenance- No tools required. ● Modular, removable design allows for easy flushing, replacement, and servicing. ● Save labour cost. |
|
| ● Made from premium materials, UV-protective. | ●Reinforced outdoor-grade PVC with hydrophobic and anti-UV formulation. ● Smooth surface & Hydrophobic material with Strong anti-blocking |
|
| ● Extended life span by 5–10 years. | ● Long and reliable service life, more than 20 years. | |
